Improve Performance with IBM Cloud Spectrum Scale Catalog Tile

In today’s rapidly evolving technological landscape, high-performance compute and storage clusters are essential for businesses to stay competitive. IBM Cloud Spectrum Scale Catalog Tile presents a cutting-edge solution that empowers organizations to achieve outstanding performance and efficiency. This article delves into the exceptional capabilities of the IBM Cloud Spectrum Scale, highlighting its key features and benefits.

Unleashing Scale File System Performance

The Scale file system performance is a crucial aspect to consider when evaluating cluster solutions. an overview of the performance metrics, providing insights into the Scale file system’s remarkable capabilities. The testing was conducted on a system with the following specifications:

Storage Nodes

The IBM Cloud Spectrum Scale operates with a cluster consisting of ten storage nodes. These nodes collectively contribute to the system’s robustness and resiliency.

NVMe Drives

With an impressive configuration of 80 NVMe drives, the Scale file system ensures exceptional data transfer rates and responsiveness. This wealth of drives optimizes storage operations, enhancing overall performance.

Raw Storage Capacity

The system boasts an astounding 256 TB of raw storage capacity, enabling organizations to accommodate vast amounts of data without compromising efficiency. This generous capacity ensures seamless scalability to meet evolving business demands.

Network Speed

To facilitate efficient data transfer, each storage node is equipped with a 100 Gbps network connection. This high-speed network infrastructure guarantees optimal performance, minimizing any bottlenecks during data transmission.

File System Capacity

The Spectrum Scale 5.1.4 provides a single 107 TB file system. This expansive capacity empowers organizations to store and access large volumes of data effortlessly.

Compute Power Unleashed

While storage is a critical component, compute power plays an equally significant role in achieving superior cluster performance. Let’s explore the compute side of the equation:

Compute Nodes

The IBM Cloud Spectrum Scale leverages 64 compute nodes to deliver exceptional compute capabilities. These nodes are instrumental in executing complex calculations and processing intensive workloads efficiently.

Instance Profile

Utilizing the cx2-16×32 instance profile, each compute node is equipped with 16 vCPUs and 32 GB of memory. This configuration ensures optimal resource allocation and empowers the cluster to handle diverse computational tasks.

Physical Cores

The cluster comprises 512 physical cores, which significantly contribute to its processing power. With this impressive core count, the compute nodes can execute parallel computations swiftly and efficiently.

Network Efficiency

The compute nodes are equipped with a high-speed network connection, operating at 24 Gbps per instance. This network infrastructure facilitates seamless communication between the compute nodes, ensuring minimal latency and optimal performance.

Analyzing Performance Results

Table 3 provides a comprehensive overview of the results obtained from testing the IBM Cloud Spectrum Scale cluster. These results highlight the exceptional performance delivered by the cluster in various aspects:

Read Bandwidth

The cluster achieves a remarkable read bandwidth of 112 GiB/sec. This impressive value essentially utilizes the full potential of the 10 100 Gbps network adapters, ensuring that no read bandwidth goes untapped. The Scale software, in conjunction with the IBM Cloud network infrastructure, maximizes data retrieval speed and efficiency.

Write Bandwidth

The write bandwidth is equally commendable, despite operating under the constraints imposed by replication. The cluster’s efficient replication mechanism ensures data integrity and reliability while maintaining excellent write performance.

Read IOPs

The IBM Cloud Spectrum Scale demonstrates its exceptional capabilities by delivering 5.4 million read IOPs. This staggering number signifies the cluster’s ability to handle a high volume of read operations simultaneously, further solidifying its position as a high-performance solution.

SPectrum Scale Storage Performance

OperationPerformanceThreads/ComputeRequest Size

Write Sequential

35 GiB/sec


4 MiB

Read Sequential

112 Gib/sec


4 MiB

Write Random

861,797 IOPS


4 KiB

Read Random

5,447,134 IOPS


4 KiB

SPectrum Scale Storage

It should be clear from a closer look at Table statistics that these are excellent values for a clustered file system. When it comes to read bandwidth, the Scale software and IBM Cloud network architecture leave nothing on the table, since the read bandwidth of 112 GiB/sec is basically all the bandwidth provided by the 10 100 Gbps network adapters. Under the limitations imposed by replication, write bandwidth is also good. Also amazing are the 5.4 million read IOPs that were provided. This is, in essence, a very high-performance product right out of the box.

The IBM Cloud Spectrum Scale Catalog Tile presents an exceptional solution for organizations seeking a high-performance compute and storage cluster. With its effortless deployment process, users can swiftly establish a compute/storage cluster tailored to their specific requirements. The Spectrum Scale’s distributed file system, coupled with its optimal utilization of hardware resources, guarantees outstanding performance and efficiency. Embrace the cloud-based future of high-performance computing today and unlock your organization’s full potential with the IBM Cloud Spectrum Scale Catalog Tile.


What is IBM Cloud Spectrum Scale?

IBM Cloud Spectrum Scale is a high-performance, scalable, and reliable file system that can be deployed on-premises or in the cloud. It offers a wide range of features, including:
High availability and scalability
Data protection and disaster recovery
Data compression and deduplication
Performance tuning and optimization
Security and compliance

What are the benefits of using IBM Cloud Spectrum Scale?

The benefits of using IBM Cloud Spectrum Scale include:
Increased performance and scalability
Improved data protection and availability
Reduced costs
Increased agility and flexibility
Enhanced security and compliance

What are the different editions of IBM Cloud Spectrum Scale?

There are three editions of IBM Cloud Spectrum Scale:
Standard Edition: This edition is designed for general-purpose use. It offers a basic set of features and is a good choice for small and medium-sized businesses.
Enterprise Edition: This edition is designed for mission-critical applications. It offers a comprehensive set of features and is a good choice for large enterprises.
Erasure Code Edition: This edition is designed for high-availability and disaster recovery applications. It uses erasure coding to protect data from failures.

What are the supported platforms for IBM Cloud Spectrum Scale?

IBM Cloud Spectrum Scale is supported on a wide range of platforms, including:
IBM Power Systems

What are the limitations of IBM Cloud Spectrum Scale?

The limitations of IBM Cloud Spectrum Scale include:
The maximum file size is 8 exabytes.
The maximum number of nodes in a cluster is 1,024.
The maximum number of files in a file system is 1 billion.

How much does IBM Cloud Spectrum Scale cost?

The cost of IBM Cloud Spectrum Scale depends on the edition and the number of nodes. For more information, please visit the IBM Cloud pricing page.
