X870E AORUS XTREME AI TOP
In order to manage demanding AI training workloads, the SSD, PSU, and chassis are paired with AI TOP Hardware, which is tuned for power efficiency, durability, and heat dissipation. Additionally, GIGABYTE offers AI TOP 100 and AI TOP 500 setup kits, which are pre-built system barebones designed for both novices and experts. The AI TOP configuration kits, which will be available in Q4 2024, provide a great deal of flexibility and future upgradeability.
AORUS X870E XTREME
The motherboards from the AORUS Z890 series are another significant announcement. The AORUS Z890 series motherboards, which are designed for the newest Intel Core Ultra CPUs, include D5 Bionic Corsa Technology, which allows for AI-enhanced overclocking for optimal DDR5 memory performance. The AORUS X870 and X870E series motherboards, which have an enhanced VRM architecture to optimize the performance of AMD Ryzen X3D series CPUs, are also included in the announcement.
For the first time, these new motherboard generations form part of the AI TOP Hardware. Showcasing the X870E AORUS XTREME AI TOP, Z890 AORUS XTREME AI TOP, and Z890 AORUS MASTER AI TOP. In addition to being designed to work with the AI TOP Utility, these motherboards are also optimized for dual-GPU setups and come with state-of-the-art Thunderbolt 5 technology, which enables local AI training.
Watch the GIGABYTE 2024 AI innovations, where GIGABYTE AI technology will be included in a number of product improvements. This all-inclusive ecosystem offers improved accessibility, performance, and adaptability in local AI computing, catering to the needs of an AI-driven future.
X870E AORUS XTREME AI TOP Features
- Using your workstation to train your own AI.
- Up to 8600MT/s for DDR5 OC.
- AMD Socket AM5: Compatible with AMD Ryzen 9000, 8000, and 7000 Series CPUs.
- VRM solution for digital twin 18+2+2 stages.
- Dual Channel DDR5: AMD EXPO Memory Module Support for 4 DIMMs.
- Improved Active Cooling for Memory Modules with DDR Wind Blade.
- M.2 EZ-Match: Magnetic alignment for simple massive heatsink installation.
- WIFI EZ-Plug: A quick and simple design for installing Wi-Fi antennas.
- EZ-Latch Plus: Screwless PCIe and M.2 slots.
- EZ-Latch Click: Screwless design M.2 heatsinks.
- Sensor Panel Link: Easy in-chassis panel configuration with an onboard video port.
- User-friendly interface features include Q-Flash Auto Scan in BIOS and SW, AIO Fan Control, and Multi-Theme.
- HWinfo’s new Power Monitor allows for real-time CPU power phase monitoring.
- Four M.2 slots, including PCIe 5.0 x4, provide ultra-fast storage.
- Effective Thermal: M.2 Thermal Guard XL & I/O ZONE AORUS LIGHTING in VRM Thermal Armor Advanced.
- Dual 10GbE LAN and Wi-Fi 7 with directional ultra-high gain antennas for quick networking
- Additional Connectivity: HDMI and Dual USB4 Type-C with DP-Alt.
- DTS: ALC1220 & Rear ESS SABRE Hi-Fi 9118 DAC & X Ultra Audio.
- Ultra Durable PCIe Armor: The PCIe x16 slot’s metal back plate for increased robustness.
- Titanium PCIe UD Slot X: two PCIe 5.0 x16 slots with improved heat dissipation and 10X graphics card robustness.
- Designed for the most cutting-edge gaming and creation PC.
An AMD motherboard from the X800 series is the best option when speed is the sole consideration. The revolutionary performance of an AMD X800-series motherboard and AMD Ryzen 9000, 8000, and 7000 Series processors allows you to play the most demanding games and complete your biggest projects. USB 4.0, overclocking, AMD EXPO technology, dual-channel DDR5 memory compatibility, and PCIe 5.0 for GPUs and NVMe are all included.
Gigabyte X870E AORUS XTREME AI TOP specs
| Category | Details |
|---|---|
| CPU Support | AMD Socket AM5 for Ryzen 9000/8000/7000 Series Processors. |
| Chipset | AMD X870E |
| Memory Support | DDR5 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(O.C) / etc., Dual Channel, up to 256GB (ECC/Non-ECC). |
| Graphics | Integrated Radeon Graphics + AS Media USB4 Controller, 2x USB4 Type-C, HDMI (4K@60Hz), Front HDMI (1080p@30Hz). |
| Audio | Realtek ALC1220 CODEC, ESS ES9118 DAC, DTS Ultra, 5.1-channel, S/PDIF Out. |
| LAN | 2x Marvell AQC113C 10GbE LAN chips. |
| Wi-Fi / Bluetooth | Qualcomm Wi-Fi 7, 802.11a/b/g/n/ac/ax/be, Bluetooth 5.3. |
| Expansion Slots | 1x PCIe 5.0 x16, 1x PCIe 5.0 x8, 1x PCIe 4.0 x2. |
| Storage Interface | 4x M.2 (PCIe 5.0 & 4.0 support), 4x SATA 6Gb/s, RAID support (0/1/5/10). |
| USB Ports | 2x USB4 Type-C, 1x USB 3.2 Gen 2 Type-A, multiple USB 3.2 Gen 1 & 2 ports. |
| Back Panel | Q-Flash Plus button, HDMI, 2x USB4 Type-C, RJ-45, antenna connectors, S/PDIF Out, 6x USB 3.2 Gen 2 Type-A. |
| Cooling | Multiple fan/water pump headers, temperature sensor headers, noise detection. |
| Form Factor | E-ATX, 30.5 cm x 26.9 cm |
