Upgrade Guide for AMD Ryzen X3D CPUs like AMD Ryzen 9 9950X3D, Ryzen 9900X3D, and Ryzen 7 9800X3D: Top Selections for Your X870 Workstations and Gaming Computers
For a few years, AMD’s X3D CPUs have ruled the gaming charts. AMD is completing its lineup with the announcement of the Ryzen 9 9950X3D and Ryzen 9 9900X3D, guaranteeing both exceptional gaming performance and top-tier workstation performance.
But having more tempting CPUs on the market does make it a little harder to decide. Is a Ryzen 7 9800X3D your choice? Or do you think a top-tier Ryzen 9 9950X3D would be a better deal?
It depends, like a lot of things.
Here is a quick recommendation for those who are interested:
- Get a Ryzen 9 9950X3D if you frequently work on workstation or heavy compute jobs (such as video editing, 3D rendering, 3D modelling, etc.) and don’t want to sacrifice gaming performance to get workstation-class performance. You should be able to enjoy the best of both worlds with it.
- A Ryzen 7 9800X3D will provide you with greater value if you enjoy high frame rates and play games on your PC most of the time. In some areas, the Ryzen 7 7800X3D, one of AMD’s last-generation processors, is still a strong choice for those on a tight budget.
Enhancements to the AMD Ryzen 9000X3D Architecture: Better and Faster in Every Way
The higher core-count processors with 3D V-Cache experienced some performance problems, even if AMD’s last-generation X3D products (7000X3D) are still remarkable for gaming. Nevertheless, AMD has made a number of microarchitectural changes with the Ryzen 9000X3D range that mitigate many of those issues.
AMD Ryzen X3D CPUs
| CPU Name | Graphics Model | Cores / Threads | Base / Max Boost Clock | L2+L3 Cache | Default TDP |
|---|---|---|---|---|---|
| AMD Ryzen 9 9950X3D | AMD Radeon Graphics | 16 / 32 | 4.3 / 5.7 GHz | 144MB | 170W |
| AMD Ryzen 9 9950X | AMD Radeon Graphics | 16 / 32 | 4.3 / 5.7 GHz | 80MB | 170W |
| AMD Ryzen 9 9900X3D | AMD Radeon Graphics | 12 / 24 | 4.4 / 5.5 GHz | 140MB | 120W |
| AMD Ryzen 9 9900X | AMD Radeon Graphics | 12 / 24 | 4.4 / 5.5 GHz | 76MB | 120W |
| AMD Ryzen 7 9800X3D | AMD Radeon Graphics | 8 / 16 | 4.7 / 5.2 GHz | 104MB | 120W |
| AMD Ryzen 7 9700X | AMD Radeon Graphics | 8 / 16 | 3.8 / 5.5 GHz | 40MB | 65W |
This implies the following for artists and gamers:
- Even 16-core CPUs like the Ryzen 9 9950X3D can fully utilise AMD 3D V-Cache technology’s gaming capabilities.
- With AMD’s basic Ryzen 9000 CPUs, you don’t lose any workstation performance.
Here is a brief overview of AMD’s Ryzen 9000X3D processor specifications. They are compatible with current AM5 motherboards, as anticipated, but if you want to access more powerful features and bandwidth for workstation workloads, you might want to switch to a newer platform.
Suggestions
- The AMD Ryzen 9 9950X3D is a 16-core, 32-thread powerhouse that combines the greatest performance for workstations and games into one package. If you require outstanding performance in both areas, this is the ideal choice.
- This 12-core, 24-thread AMD Ryzen 9 9900X3D processor is a little less powerful variant of its 16-core sibling. If you want a less expensive version of the 9950X3D without sacrificing a lot of cores, this is a wonderful choice.
- The AMD Ryzen 7 9800X3D, the current gaming performance champion, is well-suited for workstation activities, but its 8 cores will make it less competitive for workloads requiring multiple CPU cores. This is a fairly safe choice if all you want is the greatest processor for gaming.
Considerations for AMD Ryzen 9 9950X3D, Ryzen 9 9900X3D, or Ryzen 7 9800X3D Motherboard Selection
You will want to routinely manage CPU-intensive workloads if you have chosen one of AMD’s higher core count processors. You can get the most out of your new CPU without compromising performance in any way with a dependable, top-tier platform.
A new class of hybrid workstation and gaming PCs has been made available by processors like the Ryzen 9 9950X3D, which were previously unattainable. Compared to designing separate computers for work and play, you may utilise your budget more efficiently by using a single PC to get the best gaming and workstation performance.
Despite being compatible with the wide range of AM5 motherboards, there are a few things to think about before choosing one of these new processors.
Workloads: What Must You Execute?
Typically, workstations are specialised devices designed to perform well under particular workloads. With the advent of contemporary workstations, this hasn’t really altered. In the event that your workload is equally heavy on the GPU and the CPU, for instance, you will require PCIe bifurcation to ensure optimal performance from all of your GPUs in addition to a motherboard with several PCIe slots to accommodate numerous graphics cards.
In a similar vein, when working on CPU-intensive tasks, you should make sure your motherboard can consistently manage and supply the power your potent processor requires to maintain optimal CPU performance for as long as feasible. In this case, motherboards with more power phases, better chokes, clever thermal designs, etc., are what you should choose.
Motherboards for AMD Ryzen 9 9950X3D and Below: X870E vs. X870 vs. B850
You should choose a top-tier platform like X870E (or X870) to fully utilise your hardware and a dependable, contemporary power supply to guarantee the security of your system, regardless of whether the task involves a lot of CPU or GPU usage.
Similarly, a more affordable option like the B850 is a smart pick if you’re designing a more mid-range computer intended for gaming rather than workstation duties.
GODLIKE AMD Ryzen 9 9950X3D + MEG X870E: Maximum Efficiency. No concessions.
One of the most expensive motherboards available today is the MEG X870E GODLIKE, which is part of MSI’s 800-series portfolio for Ryzen 9000 processors. It has about every feature you might want in a high-end hybrid workstation and gaming PC, enabling you to fully use powerful CPUs like the Ryzen 9 9950X3D.
For enthusiasts, its cutting-edge features and robust power design make it a powerhouse. A 24+2+1 Duet Rail Power System ensures reliable power for demanding 16-core CPUs like the Ryzen 9 9950X3D.
A large 3.99-inch Dynamic Dashboard III lets you personalise the board’s dark display and monitor performance and temperatures. For premium components, MSI’s Frozr heatsink design and M.2 Shield Frozr provide the best possible thermal performance.
Two PCIe 5.0 x16 slots, up to seven M.2 sockets, dual 10GbE and 5GbE LAN connections, and full-speed Wi-Fi 7 compatibility are just a few of the many connectivity options available. Similar to other MSI 800-series motherboards, the MEG X870E GODLIKE has a number of EZ DIY features designed to make assembling a PC easier than ever.
Unleashing Performance in X3D Gaming Mode
MSI’s X3D Gaming Mode optimises AMD’s Ryzen 9000 series, including Ryzen 9000X3D CPUs. Your game performance can improve 20%!
Latency Killer: Killing DDR5 Latency on AM5
Another performance-focused feature for AMD Ryzen 9000 (X3D) CPUs is Latency Killer: Killing DDR5 Latency on AM5. This function reduces DDR5 memory latency by up to 12%, which improves performance in games and many other latency-sensitive workstation workloads.
AMD Ryzen 9 9950X3D Performance & Benchmarks: The New Workstation and Gaming Superstar
The Ryzen 9 9950X3D offers 16-core multi-core capability without sacrificing gaming performance compared to the Ryzen 7 9800X3D, the current gaming champion.
Techspot and Gamers Nexus gaming benchmarks confirm the Ryzen 9 9950X3D’s gaming capabilities, while Gamers Nexus production benchmarks name it the best consumer workstation CPU.
The Ryzen 9 9950X3D and Ryzen 7 9800X3D tie in gaming testing because they can easily keep up. The Ryzen 9 9950X3D, on the other hand, mercilessly destroys its Ryzen 7 sibling in workstation duties, providing up to 90% greater performance in workloads that require a lot of multithreading!
