MSI Servers
With the Performance Cores (P-Cores) of the most recent Intel Xeon 6 processor series, MSI Servers systems designed to provide outstanding throughput, dynamic workload flexibility, and optimal power efficiency, these servers are built for high-density performance, smooth scalability, and energy-efficient operations. MSI’s innovative platforms increase infrastructure efficiency and optimize resources while reducing total cost of ownership (TCO) for cloud-native workloads, AI-driven applications, and modern data centers.
According to Danny Hsu, general manager of MSI’s Enterprise Platform Solutions, “businesses need solutions that not only deliver performance but also enable sustainable growth and operational agility as data-driven transformation accelerates across industries.” In order to facilitate this transition, it servers with Intel Xeon 6 processors are built with high-core scalability, energy-efficient performance, and dynamic workload optimization. Organizations can increase computing density, optimize their digital ecosystems, and react more quickly and effectively to changing market needs with these capabilities.
Enterprise Servers for Compute-Intensive Workloads
With their dependable performance, smooth scalability, and maximized energy efficiency, the CX170-S5062, CX270-S5062, and CX271-S3066 corporate servers are constructed on the OCP Datacenter Modular Hardware System (DC-MHS) architecture. These servers, which are powered by P-core Intel Xeon 6500/6700 series processors with a TDP of up to 350W, offer strong processing capacity to handle demanding data center workloads.
CX170-S5062
One-unit dual-socket server for high-density, space-constrained settings. It scales memory well for data analytics and cloud workloads with 32 DDR5 DIMM slots. The server has up to 12 U.2 NVMe bays and optional E1.S and M.2 NVMe SSD for storage flexibility. Its small form factor makes it perfect for edge data centers and hyperscale installations since it maximizes rack space without sacrificing performance.
CX270-S5062
A 2U dual-socket server that is geared for PCIe expansion and maximum storage. Although its larger chassis can hold up to 24 U, it offers 32 DDR5 DIMM slots, just like the CX170-S5062.Two NVMe bays provide excellent storage density for processing huge amounts of data. With its two double-wide PCIe 5.0 x16 slots that can accommodate 400W accelerators, it is perfect for tasks involving AI, HPC, and data that demand accelerated processing. Advanced networking cards, storage controllers, and extra accelerators are supported by its broad PCIe extension capability, providing flexibility for a range of enterprise applications.
CX271-S3066
For outstanding I/O scalability, this 2U single-socket server supports up to 136 PCIe lanes and is tailored for Intel Xeon 6500/6700 series processors with P-cores. It is an affordable option for applications designed for high PCIe bandwidth and effective memory performance because of its 16 DDR5 DIMM slots. The server is ideal for cloud-native applications, virtualization, and AI inference since it offers versatile PCIe expansion with double-wide FHFL PCIe 5.0 x16 slots for up to 400W accelerators and options for up to 24 U.2 NVMe bays.
Core Compute Servers for Exceptional Compute Density and Thermal Efficiency
Both the CD270-S3061-X4 and CD270-S3061-X2 core computing DC-MHS multi-node servers are designed to operate data centers with high performance and low energy consumption. With their unified 2U chassis design and Intel Xeon 6500/6700 series with P-cores, these servers offer remarkable heat efficiency and computation density. Both 1U and 2U Extended Volume Air Cooler (EVAC) CPU Heatsinks are included to provide efficient thermal management, improving cooling performance for extended, high-density workloads.
CD270-S3061-X4
With four nodes per chassis, this 2U 4-node density-optimized server is built for optimum computation density. The Intel Xeon 6500/6700 series P-core processors that power each node support three U.2 NVMe SSD bays and sixteen DDR5 DIMM slots. Large-scale cloud and computation applications where node density is crucial will benefit greatly from its small, high-density design, which uses 1U EVAC CPU heatsinks for effective thermal control without requiring further PCIe extension.
CD270-S3061-X2
A 2U 2-node server with airflow optimization that strikes a compromise between expandability and computational performance. The Intel Xeon 6500/6700 series powers each node, which has 16 DDR5 DIMM slots and six U.2 NVMe bays for flexible storage. Eight E1.S drives may be added for increased storage density. In contrast to the CD270-S3061-X4, it has a PCIe 5.0 x16 slot for I/O expansion. Its 2U EVAC CPU heatsinks enhance thermal performance, making it appropriate for data center workloads that demand both flexible PCIe connectivity and compute power.
