The GeForce RTX 30 Series contains the Nvidia GeForce RTX 3060 vs 3060 Ti. They use NVIDIA’s second-generation RTX architecture, Ampere. Dedicated 2nd generation RT Cores and 3rd generation Tensor Cores, streaming multiprocessors, and fast GDDR6 memory are all used in these cards to deliver amazing performance. The primary gaming resolutions for both GPUs are 1080p and 1440p.
Also Read About NVIDIA RTX 4000 Ada Generation Price, Features And Specs
Features
The Ampere architecture and related NVIDIA technologies power a number of capabilities that are shared by the RTX 3060 Ti and the RTX 3060:
- RT Cores: Both have second-generation RT Cores, which allow for realistic and captivating visuals by simulating the behavior of light in the actual world through ray tracing.
- Both of them have third-generation Tensor Cores installed. NVIDIA DLSS (Deep Learning Super Sampling), a neural rendering technique that uses AI to upscale lower resolution images with near-native visual quality, is powered by these AI-specialized cores. It increases frame rate and improves image quality.
- Both are compatible with NVIDIA Reflex, a set of technologies designed to measure and lower system latency in competitive games for improved aim and quicker reactions.
- NVIDIA Studio: With specialised drivers and tools, these GPUs improve workflows and speed up creative projects by providing AI acceleration in popular creative programs. Additionally supported are RTX Accelerated Creative Apps.
- With features like noise reduction and simulated backdrops for streams, voice chats, and video conferences, the NVIDIA Broadcast App turns any space into a home studio.
- NVIDIA Encoder (NVENC): With 7th Generation NVENC, these cards provide cutting-edge streaming features for lag-free, seamless live streaming with image quality and performance that will blow you away.
- Drivers: Both support Studio Drivers for artistic applications and Game Ready Drivers for the best performance and dependability in gaming.
- For four 7680×4320 displays, each cards provide three DisplayPort 1.4a outputs and one HDMI 2.1 connection.
- VR Ready, GeForce Experience, Ansel, FreeStyle, ShadowPlay, Highlights, Omniverse, GPU Boost, OpenGL 4.6, CUDA 8.6, Vulkan (1.2 on 3060 Ti, 1.3 on 3060), and DirectX 12 Ultimate are supported by both. In contrast to the 3060 Ti, which supports OpenCL 2, the 3060 supports OpenCL 3.
- Physical specifications: Both the reference and Founder’s Edition designs take up two slots and measure 9.5″ (242 mm) in length and 4.4″ (112 mm) in width. One PCIe 8-pin auxiliary power connector is needed for both (a 12-pin converter is available).
Also Read About NVIDIA GeForce RTX 5090 vs RX 7900 XTX: Which Is Better?
Benefits and Drawbacks
The following is a synopsis of each card’s main benefits and drawbacks:
Benefits of the GeForce RTX 3060 Ti
- Noticeably improved gaming performance (around 17–23% faster on average across resolutions).
- Greater total benchmark scores.
- Enhanced effective speed.
- Performance-wise, it is closer to the more expensive RTX 3070.
- More transistors, TMUs, ROPs, shading units, RT cores, Tensor cores, and CUDA cores.
- Higher memory bandwidth and a wider memory bus.
- Increased pixel rate, texture rate, and floating-point performance.
- User ratings for gaming, performance, value, dependability, and quiet operation are generally higher.
- Technical City suggested this option based on performance.
Drawbacks
- Lower VRAM (8GB as opposed to 12GB on the typical 3060).
- Higher power demand and TDP (200W vs. 170W) are common.
- A little slower turbo/boost clock speed.
- Both the effective memory clock and the memory clock are a little slower.
- An older version of OpenCL (2 vs 3).
Benefits of the GeForce RTX 3060
- More VRAM (12GB as opposed to the 3060 Ti’s 8GB).
- Reduced power consumption and TDP (170W vs. 200W).
- Increased turbo/boost clock speed.
- A more efficient and quicker memory clock.
- A more recent version of OpenCL (3 vs. 2).
- A little better deal when comparing MSRP and performance.
- More market share than the 3060 Ti.
- The MSRP is lower ($329 compared to $399 for the 3060 Ti).
Drawbacks
- Poorer gaming performance, typically 17–23% slower.
- Reduced overall benchmark scores.
- Reduced efficient speed.
- Reduced transistors, TMUs, ROPs, shading units, Tensor cores, RT cores, and CUDA cores.
- Reduced memory bandwidth and a smaller memory bus.
- Reduced texture rate, pixel rate, and floating-point performance.
- The benefit of VRAM is frequently negligible for the desired resolutions (1080p and 1440p).
- Several categories have somewhat lower user ratings.
Also Read About NVIDIA GeForce GTX 1080 Ti Vs RTX 4070 Specs And Price
Nvidia GeForce RTX 3060 vs 3060 Ti Benchmark
| Benchmark Type / Specific Test | RTX 3060 Ti | RTX 3060 | Notes |
| Aggregate synthetic score | 51.221 (51.22 +19.3%) | 42.941 (42.94) | RTX 3060 Ti has a 19.3% higher aggregate score |
| Passmark | 20379 (+19.3%) | 17085 | RTX 3060 Ti leads |
| 3DMark 11 Performance GPU | 37941 (+31.1%) | 28939 | RTX 3060 Ti leads by 31.1% |
| 3DMark Vantage Performance | 78597 | 81033 (+3.1%) | RTX 3060 leads by 3.1% |
| 3DMark Fire Strike Graphics | 28145 (+29.8%) | 21689 | RTX 3060 Ti leads by 29.8% |
| 3DMark Cloud Gate GPU | 153968 (+27.5%) | 120756 | RTX 3060 Ti leads by 27.5% |
| GeekBench 5 OpenCL | 109075 (+23.6%) | 88251 | RTX 3060 Ti leads by 23.6% |
| 3DMark Ice Storm GPU | 615311 (+9.6%) | 561364 | RTX 3060 Ti leads by 9.6% |
| GeekBench 5 Vulkan | 115945 (+28.9%) | 89918 | RTX 3060 Ti leads by 28.9% |
| GeekBench 5 CUDA | 128321 (+30%) | 98715 | RTX 3060 Ti leads by 30% |
| SPECviewperf 12 – 3dsmax-05 | 129 | 201 (+55.8%) | RTX 3060 leads by 55.8% |
| Average FPS (Full HD) | 139 (+23%) | 113 | RTX 3060 Ti is 23% faster in 1080p |
| Average FPS (1440p) | 78 (+18.2%) | 66 | RTX 3060 Ti is 18% faster in 1440p |
| Average FPS (4K) | 49 (+16.7%) | 42 | RTX 3060 Ti is 17% faster in 4K |
Nvidia GeForce RTX 3060 vs 3060 Ti Gaming
| Gaming performance | RTX 3060 Ti | RTX 3060 | Notes |
| Cyberpunk 2077 (Full HD, Low) | 132 (+67.1%) | 79 | RTX 3060 Ti leads |
| Dead Island 2 (Full HD, Low) | 325 (+71.1%) | 190-200 | RTX 3060 Ti is 71% faster in this specific test |
| Battlefield 5 (Full HD, Ultra) | 114 (-20.2%) | 130-140 (+20.2%) | RTX 3060 leads in this specific test |
| Cyberpunk 2077 (1440p, Ultra) | 54 (+38.5%) | 39 | RTX 3060 Ti leads |
| Forza Horizon 4 (1440p, Ultra) | 150 (+26.1%) | 110-120 | RTX 3060 Ti leads |
| Dead Island 2 (4K, High) | 5 (-700%) | 40-45 (+700%) | RTX 3060 is 700% faster in this specific test |
| Grand Theft Auto V (4K, High) | 107 (+30.5%) | 82 | RTX 3060 Ti leads |
Nvidia GeForce RTX 3060 vs 3060 Ti price
| Specification | RTX 3060 Ti | RTX 3060 |
| Launch Price (MSRP) | $399 | $329 |
| Example Market/Retail Prices (USD) | ~$409 – $526 | ~$330 – $454 |
Also Read About NVIDIA GeForce RTX 5060 Ti Release Date, Price And Specs
Nvidia GeForce RTX 3060 vs 3060 Ti spec
| Specification | RTX 3060 Ti | RTX 3060 |
| GPU Architecture | Ampere | Ampere |
| GPU Code Name | GA104 | GA106 |
| NVIDIA CUDA Cores | 4864 | 3584 |
| Shading Units | 4864 | 3584 |
| Tensor Cores | 152 | 112 |
| RT Cores | 385 (2nd Generation) | 285 (2nd Generation) |
| Texture Mapping Units (TMUs) | 152 | 112 |
| Render Output Units (ROPs) | 80 | 48 |
| Transistors | 17400 million | 12000 million |
| Manufacturing Process | 8 nm | 8 nm |
| Base Clock (GHz) | 1.41 (1410 MHz) | 1.321 (1320 MHz) |
| Boost Clock (GHz) | 1.67 (1665 MHz, 1670 MHz GPU turbo) | 1.78 (1777 MHz, 1780 MHz GPU turbo) |
| Floating-Point Performance | 16.2 TFLOPS | 12.76 TFLOPS(12.74 TFLOPS) |
| Pixel Rate | 133.2 GPixel/s | 85.44 GPixel/s |
| Texture Rate | 253.1 GTexels/s | 199.36 GTexels/s(199.0 GTexels/s5) |
| Standard Memory Config | 8 GB GDDR6 / 8 GB GDDR6X1 (8 GB) | 12 GB GDDR6 / 8 GB GDDR61 (12 GB / 8 GB4, 12 GB) |
| Memory Type | GDDR6 / GDDR6X4 (GDDR6) | GDDR6 |
| Memory Interface Width | 256-bit | 192-bit / 128-bit (192-bit) |
| Memory Clock Speed | 1750 MHz | 1875 MHz |
| Effective Memory Speed | 14000 MHz | 15000 MHz |
| Memory Bandwidth | 448 GB/s | 360 GB/s |
| PCI Express Version | Gen (PCIe 4.0 x1617) | Gen (PCIe 4.0 x1617) |
| Resizable BAR | Yes | Yes |
| Ray Tracing Support | Yes | Yes |
| DLSS Support | Yes | Yes |
| NVIDIA Reflex Support | Yes | Yes |
| NVIDIA Broadcast Support | Yes | Yes |
| NVIDIA Studio Support | Yes | Yes |
| Game Ready Drivers | Yes | Yes |
| Studio Drivers | Yes | Yes |
| NVIDIA Encoder (NVENC) | 7th Generation | 7th Generation |
| NVIDIA Decoder | 5th Generation | 5th Generation |
| CUDA Capability | 8.6 | 8.6 |
| VR Ready | Yes | Yes |
| DirectX Version | 12 Ultimate(12 Ultimate (12_2)) | 12 Ultimate(12 Ultimate (12_2)) |
| Shader Model | 6.5 | 6.7 |
| OpenGL Version | 4.6 | 4.6 |
| OpenCL Version | 2.019 (2) | 3.019 (3) |
| Vulkan Version | 1.219 | 1.319 |
| Maximum Digital Resolution | 7680×4320 | 7680×4320 |
| Standard Display Connectors | 1x HDMI, 3x DisplayPort(HDMI(2), 3x DisplayPort(3)) | 1x HDMI 2.1, 3x DisplayPort 1.4a (HDMI(2), 3x DisplayPort(3)) |
| HDMI Version | HDMI 2.1 | HDMI 2.1 |
| DisplayPort Version | DisplayPort 1.4a | DisplayPort 1.4a |
| Multi Monitor Support | 4 | 4 |
| HDCP | 2.3 | 2.3 |
| Card Dimensions (Length) | 9.5″ (242 mm) (242 mm) | 9.5″ (242 mm) (242 mm) |
| Card Dimensions (Width) | 4.4″ (112 mm) (112 mm) | 4.4″ (112 mm) (112 mm) |
| Card Dimensions (Slot) | 2-Slot (2-slot) | 2-Slot (2-slot) |
| Maximum GPU Temperature | 93°C | 93°C |
| Graphics Card Power (TDP) | 200 Watt | 170 Watt |
| Required System Power | 600 Watt (600W) | 550 Watt |
| Supplementary Power Connectors | 1x PCIe 8-pin (adapter to 1x 12-pin included) (1x 12-pin) | 1x PCIe 8-pin (adapter to 1x 12-pin included) (1x 12-pin) |
