MediaTek Dimensity 6100+
For both mainstream and entry-level 5G smartphones, this extremely powerful 5G SoC offers fantastic gaming experiences, speedy networking with specialized upgrades, enhanced photography, and remarkable power efficiency.
Unleashing 5G’s True Potential for Mainstream Smartphones
3GPP R16 Standard Modem
With the most recent connectivity improvements now being implemented by international cellular providers, the Dimensity 6100+ comes with a 3GPP Release-16 standard 5G modem.
Faster 5G with Greater Range
Up to 3.3Gb/s 5G downlink via 2CC carrier aggregation is made possible by addressing a maximum of 140MHz cellular spectrum. This is up to 40% faster downlink speeds in metropolitan areas and up to 30% faster in suburbs when compared to competing options. By combining the benefits of low and mid-band, CA may implement mixed duplex FDD+TDD, giving smartphones access to faster speeds and a wider range. Additionally, carrier aggregation allows for a smooth transition between two 5G connection areas across a coverage layer, giving consumers more than 30% more throughput layer coverage than they would have without CA.
MediaTek 5G UltraSave 3.0+
In typical 5G sub-6GHz connectivity circumstances, MediaTek 5G Ultra Save 3.0+ offers a full suite of R16 power-saving improvements in addition to MediaTek’s proprietary optimizations that lead to 13–30% higher power efficiency than competing options.
Situationally Intelligent Enhancements
MediaTek 5G modem understands the connection environment when using high-speed rail, the subway, or a car underground. It then applies situationally intelligent upgrades that give 20% faster downlink rates than competing options.
LB+LB ENDC and 8-layer DL MIMO Support
Many major international cellular carriers now need dual, low-band ENDC and 8-layer DL MIMO for this class, which MediaTek Dimensity 6100+ enables.
Additional Key Features
108MP with AI-Camera
Support for 108MP camera sensors results in incredibly detailed images, while cutting-edge noise reduction techniques guarantee that selfies and low-light shots are always crisp and clear.
- Hardware acceleration for depth perception and two cameras
- AI-camera improvements including single camera bokeh and AI-color
Billion Color Display
With billions of color screens that can show real 10-bit images and videos, you can see true colors without contours, improving the user experience.
Support for 120Hz display speeds reduces eye fatigue and offers a remarkably fluid user experience, including app animations and page scrolling.
MediaTek HyperEngine 3.0 Lite Gaming Technologies
improvements to smartphone gaming that guarantee players stay connected at all times by offering longer playtime, quicker network response, and more dependable connectivity.
- 3G Call/Data Concurrency: No missed calls while playing games
- Demanding scenarios, fluid game engine performance, and intense gameplay
- Intelligent connection prediction combined with 5G/Wi-Fi concurrency
Exceptionally Power-efficient & Compact Platform
Even for demanding smartphone users, the TSMC N6 (6nm-class) chip’s fabrication process guarantees its low power consumption, extending battery life. Additionally the MediaTek engineering advancements have produced a more compact architecture that allows device designers greater creative freedom.
MediaTek Dimensity 6100+ Specs
| Processor | CPU Type(s) | 2X Arm Cortex-A76 up to 2.2GHz 6X Arm Cortex-A55 up to 2.0GHz |
| Cores | Octa (8) | |
| CPU Bit | 64-bit | |
| Heterogeneous Multi-Processing | Yes | |
| Memory & Storage | Memory Type | LPDDR4x |
| Max Memory Frequency | 2133MHz | |
| Storage Type | UFS 2.2 | |
| Graphics | GPU Type | Arm Mali-G57 MC2 |
| Camera | Max Camera ISP | Up to 108MP 16MP + 16MP |
| Display | Max Display Resolution Max Refresh Rate | 2520 x 1080 Up to 120Hz |
| Connectivity | Cellular Technologies | 2G / 3G / 4G / 5G Multi-Mode, 4G Carrier Aggregation (CA), 5G Carrier Aggregation (CA), EDGE, 4G FDD / TDD, 5G FDD / TDD, GSM, TD-SCDMA, WDCDMA |
| Specific Functions | SA & NSA modes; SA Option2, NSA Option3 / 3a / 3x, NR TDD Band, NR FDD Band, DSS, NR DL 2CC, 140 MHz bandwidth, 256QAM NR UL 2CC, 256QAM VoNR, Dual VoNR, Dual 5G SIM, EPS fallback | |
| Peak Download Speed | 3.3Gbps | |
| GNSS | GPS L1CA+L5 BeiDou B1I+ B2a Glonass L1OF Galileo E1 + E5a QZSS L1CA+ L5 NavIC | |
| Wi-Fi Antenna | 1T1R | |
| Wi-Fi | Wi-Fi 5 (a/b/g/n/ac) | |
| Bluetooth | 5.2 |
