AMD Ryzen 9 PRO 7945
Built on top of the Raphael Zen 4 architecture. Made utilizing the 5nm manufacturing node from TSMC. Has 24 threads and 12 cores. Boost clock up to 5.4 GHz and base clock of 3.7 GHz. Has an integrated AMD Radeon Graphics processor that operates between 400 and 2200 MHz. Supports DDR5 memory and PCIe 5.0. Featuring 64 MB of L3 cache. Provides enhanced stability by supporting ECC memory. X670, B650, and A620 chipsets are compatible with the AM5 socket. Made to fit business-class PCs and workstations. AMD Ryzen 7 7800X3D
Additionally, TSMC’s 5nm technology was used to build on AMD’s Zen 4 architecture. Includes 16 threads and 8 cores. 4.2 GHz is its base frequency, and it can reach 5.0 GHz as its boost clock. 3D V-Cache technology’s enormous 96 MB of L3 cache is the most notable feature.Compatible with DDR5 memory and PCIe 5.0, it was created for the AM5 platform. Included for minimal display requirements are integrated Radeon graphics. Feature AMD Ryzen 9 PRO 7945 AMD Ryzen 7 7800X3D Architecture Zen 4 (Raphael) Zen 4 (Raphael) with 3D V-Cache Cores / Threads 12 Cores / 24 Threads 8 Cores / 16 Threads Base / Boost Clock 3.7 GHz / Up to 5.4 GHz 4.2 GHz / Up to 5.0 GHz L3 Cache 64 MB 96 MB (Enhanced with 3D V-Cache) Integrated Graphics AMD Radeon Graphics (400–2200 MHz) AMD Radeon Graphics (400–2200 MHz) Socket AM5 AM5 Process Node TSMC 5nm TSMC 5nm PCIe Support PCIe 5.0 PCIe 5.0 ECC Memory Support Yes Yes Target Market Workstations, Business PCs Gaming PCs
AMD Ryzen 9 PRO 7945
Strong multi-core performance because of the design’s 12-core/24-thread architecture. Demonstrates proficiency in software development, rendering, content production, and productivity tasks. Excels at CPU-bound jobs and programs like Blender and Adobe Premiere Pro. AMD Ryzen 7 7800X3D
Offers gaming and single-threaded performance that is leading the class. Performance in cache-sensitive applications is significantly enhanced by the additional L3 cache, despite having fewer cores than the 7945. Great for tasks that need minimal latency, such software, emulation, and code compilation requirements. You can also read Intel Core Ultra 5 125H vs 135H Mobile CPU Specs
AMD Ryzen 9 PRO 7945
Ability to run high-end current games, particularly when combined with a powerful GPU. The 3D V-Cache included in CPUs with gaming optimisation is absent, and it is not especially tuned for gaming. Due to its higher latency and lower cache, it performs worse than the 7800X3D in gaming benchmarks, despite decent frame rates in most games. AMD Ryzen 7 7800X3D
The greatest gaming CPU on the market right now. Several CPUs with more cores perform better because of its 3D V-Cache. Assassin’s Creed Valhalla, Elden Ring, and Cyberpunk 2077 may reach high frame rates. Ideal for 1080p, 1440p, and 4K games with a strong GPU. AMD Ryzen 9 PRO 7945
More power-efficient than the majority of high-end Ryzen CPUs, it has a 65W TDP rating. When there is a high load, the actual power demand might reach 88W. Better thermal efficiency and a cooler operating temperature make it perfect for small or large systems. AMD Ryzen 7 7800X3D
TDP has a 120W rating, which is much more than the Ryzen 9 PRO 7945. A full load might result in real power usage of up to 160W. Runs hotter, particularly when playing games and working for extended periods. Maintains thermal performance and boost clocks with enough cooling. Metric AMD Ryzen 9 PRO 7945 AMD Ryzen 7 7800X3D Cinebench R23 (Single-Core) ~1,955 ~2,000 Cinebench R23 (Multi-Core) ~28,905 ~19,000 Geekbench 5 (Single-Core) ~2,800 ~2,700 Geekbench 5 (Multi-Core) ~16,832 ~14,000 TDP 65W 120W PPT (Max Power) 88W 162W Max Operating Temp 95°C 89°C
You can also read AMD Ryzen Threadripper PRO 9000 WX Series Specs And Price
AMD Ryzen 9 PRO 7945
The dual-channel design supports DDR5-5200 memory. 128 GB is the maximum amount of memory that may be supported. Stability is guaranteed for mission-critical applications with ECC memory support. AMD Ryzen 7 7800X3D
Enables dual-channel DDR5-5200 memory capability. Capable of managing 128 GB of RAM. While it is available, ECC is not frequently utilised in gaming settings. Feature AMD Ryzen 9 PRO 7945 AMD Ryzen 7 7800X3D Memory Support DDR5-5200 DDR5-5200 Max Memory Capacity Up to 128 GB Up to 128 GB Memory Channels Dual-channel Dual-channel ECC Support Yes Yes Motherboard Chipsets Compatible with X670E, X670, B650E, B650, A620 Compatible with X670E, X670, B650E, B650, A620
You can also read NVIDIA Grace CPU C1 Arm Processor For The Data Center
AMD Ryzen 9 PRO 7945
For tasks that require threading and multitasking, a high core count is ideal. Cooler and more energy-efficient. Extended stability and ECC are examples of professional-grade functionality. Ideal for workplaces and for developers and designers. AMD Ryzen 7 7800X3D
Gaming performance is exceptional because of the huge 3D V-Cache. Applications with only one thread benefit from higher base clocks. Perfect for gamers and streamers that want to compete. Outstanding value for the money for gamers. AMD Ryzen 9 PRO 7945
Games are not optimised, and there is no 3D V-Cache. Performance on the single thread is a little worse than on gaming CPUs. Due to less emphasis on overclocking, there is less enthusiast appeal. AMD Ryzen 7 7800X3D
Increased heat output and power drain. Performance issues with multiple threads in comparison to CPUs with more cores, such as the Ryzen 9 PRO 7945. Its 3D V-Cache architecture limits overclocking capability. You can also read AMD Ryzen 5 9600X vs Ryzen 5 7600X Performance, Price
Processor Price (USD) AMD Ryzen 9 PRO 7945 ~$430 AMD Ryzen 7 7800X3D ~$449
Specification AMD Ryzen 9 PRO 7945 AMD Ryzen 7 7800X3D
Architecture Zen 4 (Raphael) Zen 4 (Raphael) with 3D V-Cache
Process Node TSMC 5nm TSMC 5nm
Cores / Threads 12 Cores / 24 Threads 8 Cores / 16 Threads
Boost Clock Up to 5.4 GHz Up to 5.0 GHz
L3 Cache 64 MB 96 MB (3D V-Cache)
Integrated Graphics AMD Radeon (2200 MHz max) AMD Radeon (2200 MHz max)
Max Operating Temp. ~95°C ~89°C
Memory Support DDR5-5200, ECC, Dual Channel DDR5-5200, ECC, Dual Channel
Max Memory Capacity Up to 128 GB Up to 128 GB
PCIe Version PCIe 5.0 PCIe 5.0
Use Case Business, Workstation, Enterprise Gaming, Enthusiast Desktop
Ray Tracing / AVX-512 Supported Supported
Unlocked for OC Yes No (Limited due to 3D V-Cache)
