RTX 4070 Super Vs 7800 XT
Memory and graphics architecture differ substantially between AMD Radeon RX 7800 XT and NVIDIA GeForce RTX 4070 Super. AMD’s RDNA 3 architecture uses 5nm and 6nm process nodes in the 7800 XT for power and efficiency. TSMC 4nm manufacturing and Ada Lovelace design improve AI and power efficiency in NVIDIA’s 4070 Super.
Also Read About AMD vs NVIDIA GPU, Which is a better buy, AMD or Nvidia?
The RX 7800 XT has 16GB of GDDR6 memory and improved VRAM on a 256-bit bus with 624 GB/s bandwidth. More suitable for high-resolution texturing and future games. Memory-intensive games, especially 4K ones, may impede the 4070 Super, which has 12GB of faster GDDR6X memory and a 192-bit bus with 504 GB/s.
The more powerful NVIDIA solution speeds up ray tracing. The 4070 Super can use DLSS 3.0 with frame generation because it has third-generation RT cores and fourth-generation Tensor cores, which boosts frame rates in games that support it. In contrast, the 7800 XT, which supports FSR 3 and has second-generation Ray Accelerators, is becoming better but still falls short of DLSS in terms of smoothness and visual quality.
AMD gets a leg up in terms of display outputs. Next-generation monitors benefit from RX 7800 XT’s DisplayPort 2.1 ultra-high resolutions and refresh rates. The RTX 4070 Super supports DisplayPort 1.4a, which is functional but less bandwidth-intensive than AMD’s.
Both cards have good software and functionality, but NVIDIA’s ecosystem is better. The RTX 4070 Super supports Studio Drivers for creative work, Broadcast for AI-enhanced streaming, and NVIDIA Reflex for low-latency gameplay. AMD’s Radeon Chill, Anti-Lag, and Boost boost performance and efficiency, but it lacks NVIDIA’s AI.
Gaming Performance
Resolution 1440p
- In conventional rasterized games like Cyberpunk 2077 and Resident Evil 4, the RX 7800 XT often matches or exceeds the RTX 4070 Super.
- Dedicated RT cores and DLSS 3.0 support give the RTX 4070 Super a competitive edge in ray-traced games, improving frame rates and visual fidelity.
4-K Resolution
Adjusted settings let both GPUs perform 4K gaming. In memory-intensive games, the RX 7800 XT’s bigger VRAM helps, but the RTX 4070 Super performs better in ray-traced 4K games.
AMD 7800 XT Vs 4070 Super Benefits & Drawbacks
7800 XT Benefits:
- Greater VRAM: 16GB of GDDR6 memory improves performance in programs that need a lot of memory and prepares for future games.
- Wider Memory Bus: 256-bit bus offers higher memory bandwidth, beneficial for high-resolution textures and complex scenes.
- Better Value: Lower MSRP makes it a cost-effective choice for gamers focusing on rasterization performance.
Also Read About AMD Radeon RX 8000 Series: Expected Features And Specs
Drawbacks:
- Ray Tracing Performance: Lags behind in ray-traced workloads compared to the RTX 4070 Super.
- Power Consumption: 263W TDP may demand more powerful cooling and power supply.
RTX 4070 Super Benefits:
- Ray Tracing & DLSS: Better graphics and performance in compatible games are made possible by superior ray tracing capabilities and DLSS 3.0 support.
- Power Efficiency: Lower TDP of 220W results in better energy efficiency and potentially quieter operation.
- Creative Workloads: Excels in applications like Blender, making it a better choice for content creators.
Disadvantages:
- Lower VRAM: 12GB GDDR6X may be limiting in future titles with higher memory requirements.
- More expensive: Some customers might feel that the $100 price difference between the MSRP and the RX 7800 XT is not enough to counterbalance the performance gains.
4070 super vs 7800 XT benchmark specs
| Benchmark Test | RX 7800 XT | RTX 4070 Super | Winner |
|---|---|---|---|
| 3DMark Time Spy Graphics | 20,048 | 20,945 | RTX 4070 Super |
| 3DMark Time Spy Extreme | 8,933 | 8,608 | RX 7800 XT |
| 3DMark Port Royal (Ray Tracing) | 10,026 | 11,293 | RTX 4070 Super |
| 3DMark Speed Way (Ray Tracing) | 3,671 | 4,520 | RTX 4070 Super |
Gaming Benchmarks (Average FPS)
| Game Title | Resolution & Settings | RX 7800 XT | RTX 4070 Super | Winner |
|---|---|---|---|---|
| Cyberpunk 2077 | 1440p Ultra | 95 FPS | 90 FPS | RX 7800 XT |
| Cyberpunk 2077 (Ray Tracing) | 1440p Ultra RT | 42 FPS | 60 FPS | RTX 4070 Super |
| Starfield | 4K High | 48.7 FPS | 39.5 FPS | RX 7800 XT |
| Retinal | 1440p Ultra | 104 FPS | 100 FPS | RX 7800 XT |
| Shadow of the Tomb Raider | 4K Ultra | 53 FPS | 60 FPS | RTX 4070 Super |
| Hitman 3 | 4K Ultra | 116 FPS | 120 FPS | RTX 4070 Super |
Pricing Comparison
| Graphics Card | Launch MSRP (USD) | Current Price (USD) |
|---|---|---|
| AMD Radeon RX 7800 XT | $499 | ~$499 |
| NVIDIA GeForce RTX 4070 Super | $599 | ~$599 |
AMD RX 7800 XT Vs RTX 4070 super spec
| Feature | AMD Radeon RX 7800 XT | NVIDIA GeForce RTX 4070 Super |
|---|---|---|
| Architecture | RDNA 3 | Ada Lovelace |
| CUDA/Stream Processors | 3,840 Stream Processors | 7,168 CUDA Cores |
| Base Clock | 2,124 MHz | 1,980 MHz |
| Boost Clock | 2,430 MHz | 2,475 MHz |
| Memory | 16GB GDDR6 | 12GB GDDR6X |
| Memory Bus | 256-bit | 192-bit |
| Memory Bandwidth | 624.1 GB/s | 504.2 GB/s |
| TDP | 263W | 220W |
| Power Connectors | 2x 8-pin PCIe | 1x 16-pin (12VHPWR) |
Also Read About AMD Radeon RX 6700 XT Vs RTX 4070: Which GPU Is Better?
In conclusion
- In the midrange GPU market, the AMD Radeon RX 7800 XT and the NVIDIA GeForce RTX 4070 Super are both strong competitors. Personal needs should guide your choice:
- If you value superior rasterization performance, more VRAM, and affordability, go with the RX 7800 XT.
If you need more efficiency for creative tasks, DLSS support, and superior ray tracing performance, go with the RTX 4070 Super.
